Super-Solid SL 554 DE FI IP54 Extension Lead 5ways 5m H07RN-F 3G1.5
Description
Description
- The top quality and break-resistant plastic housing with a wide surface guarantees easy and safe operation.
- Connecting cable with an RCD plug.
- With circuit breaker plug 30 mA to protect against electrical shocks.
- With illuminated 2-pole switch with protection cover.
- Dust- and splash-water protected, widely-spaced sockets fitted with seals and self-closing covers to protect against contamination.
- Sockets with increased touch protection in a practical 45° arrangement.
- With a very stable suspension bracket for wall fixing.
RCD personal protection switch
A residual current circuit breaker (RCD) is an electrical protective device used primarily to protect against electric shocks. The RCD detects the difference between the incoming and outgoing current in a circuit. If a fault current occurs, for example due to an insulation fault or a current flow via an unwanted discharge such as a person, the RCD switches off the circuit. This significantly reduces the risk of electric shock or fire caused by a fault current. When used as personal protection, a residual current device must trip and interrupt the circuit at a residual current of 30mA at the latest.
Technical data
Technical data
- Cable designation: H07RN-F 3G1,5
- Cable length: 5 m
- Width of product (without packaging): 10 cm
- Weight of product (without packaging): 1,44 kg
- Height of product (without packaging): 51 cm
- Length of product (without packaging): 11,50 cm
- Colour: yellow
- Usage: outdoor
- Type of fastening: Fastening with screw
- With surge protection: No
- Max. electr. load capacity: 3680 W
- Protection: Not applicable
- With residual current circuit breaker (RCCB): Yes
- Nominal input voltage: 230 V
- Type of plug: Angle plug
- Number of socket outlets total: 5
- Socket outlet arrangement: 45°
- USB type output socket: Not applicable
- Degree of protection (IP): IP54
- Suitable for outdoor area: Yes
- Cable quality: Rubber-Neoprene
- Suitable for 19 inch rack mounting: No
- Suitable for built-in mounting: No
- With hand/ foot switch: No
- With wireless control: No
- With interference suppressor filter: No
- Main Follow function: No
Downloads
Downloads
Accessories
Accessories
1160670
Fastening and fixing strap
