RCD Protected Cable IP54 with Powerblock 5m black H07RN-F 3G1.5
Description
Description
- Ideal for hard outdoor use.
- With circuit breaker plug 30 mA to protect against electrical shocks.
- Function test indicator.
- When touched by current-conducting leads or parts, the current supply is automatically interrupted to protect against dangerous bodily injury and electric shocks.
- Quality rubber cable with 4-way dust- and water-jet protected safety socket outlets.
- Residual current: 30 mA.
- Working temperature: -25 °C bis 40 °C.
Dust and splash-proof
Protection against contact, protection against dust deposits inside. Also protected against splash water from all directions
RCD personal protection switch
An RCD (residual current circuit breaker) is an electrical protective device that is primarily used to protect against electric shocks. The RCD recognises the difference between the incoming and outgoing current in a circuit and automatically switches off the circuit in the event of a residual current. When used for personal protection, a residual current device must trip and interrupt the circuit at a residual current of 30mA at the latest.
Technical data
Technical data
- Cable designation: H07RN-F 3G1,5
- Cable length: 5 m
- Cable quality: Rubber-Neoprene
- Width of product (without packaging): 30,50 cm
- Weight of product (without packaging): 1,28 kg
- Height of product (without packaging): 9 cm
- Length of product (without packaging): 32 cm
- With Powerblock: Yes
Downloads
Downloads
All products are subject to technical changes
